Ford C-MAX II (2010-2015) charge port light ring Wiring diagrams

This page contains all the electrical diagrams for the component. charge port light ring, in which he is found in the car Ford C-MAX II (2010-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram charge port light ring (1 of 2)

Wiring diagram charge port light ring for Ford C-MAX II (2010-2015)

Get access

ANTI-LOCK BRAKE SYSTEM (ABS) MODULE BATTERY BATTERY FUSE ASSEMBLY BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BATTERY MONITORING SENSOR BLK WIRE BLOWER MOTOR RELAY BLU WIRE BLU/WHT WIRE BRAKE PEDAL POSITION (BPP) SWITCH BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE CHARGE PORT LIGHT RING COOLANT WATER PUMP 1 DC/DC CONVERTER MODULE ENGINE COOLING FAN RELAY FUEL INJECTOR 1 FUEL INJECTOR 2 FUEL INJECTOR 3 FUEL INJECTOR 4 FUSE FUSE 13 FUSE 17 FUSE 18 FUSE 10 FUSE 2 FUSE 1 FUSE 20 FUSE 21 FUSE 24 FUSE 31 FUSE 4 FUSE 3 FUSE 9 FUSE 7 FUSE 8 FUSE FUSE 30 FUSIBLE LINK (22 GA- GRN/RED WIRE GRY/RED WIRE GRY/VIO WIRE GRY/YEL WIRE HORN RELAY MEGA FUSE 1 MEGA FUSE 2 NCA WHT WIRE NCA WIRE PCM POWER RELAY POWER STEERING CONTROL MODULE (PSCM) POWERTRAIN CONTROL MODULE (PCM) RED WIRE TO BATTERY JUNCTION BOX (BJB) (DIAGRAM 2 OF 6) TO FUSE 33 (DIAGRAM 3 OF 6) FUSE TO SPLICE 115 (DIAGRAM 2 OF 6) TRANS- MISSION FLUID PUMP VACUUM PUMP CUT-OFF RELAY VIO/GRY WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE WIPER RUN/PARK RELAY YEL WIRE YEL/BLU WIRE YEL/RED WIRE

Go to component: -> Power distribution circuit (1 of 6) -> CHARGE PORT LIGHT RING

Wiring diagram charge port light ring (2 of 2)

Wiring diagram charge port light ring for Ford C-MAX II (2010-2015)

Get access

BATTERY BATTERY FUSE ASSEMBLY (ON BATTERY) BATTERY JUNCTION BATTERY MONITORING SENSOR (ON BATTERY) BLK WIRE BLK/GRY WIRE BLU/WHT WIRE BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BRN/WHT WIRE CHARGE PORT (REAR OF LEFT FRONT WHEELWELL) CHARGE PORT LIGHT RING CHARGER COOLING ACTUATOR (RIGHT REAR OF HIGH VOLTAGE BATTERY COMPT) COMPUTER CP RTN CP SIG DATA LINES FEEDBACK FUSE FUSE FUSE FUSIBLE LINK GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRN/VIO WIRE GRN/YEL WIRE GRY/BLU WIRE GRY/VIO WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY ENERGIZED HS CAN+ HV- INLINE FUSE 1 (LEFT SIDE INLINE FUSE 2 LIN 8 ENS MEGA FUSE 2 MICRO BODY CONTROL MODULE (BCM) (LOWER RIGHT SIDE OF DASH) MTR NCA WIRE OF ENGINE COMPT) ORG/ WIRE POWER DISTRIBUTION SYSTEM RED WIRE RELAY RESISTOR SYSTEM TCM POWER VBATT VIO/GRY WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE

Go to component: -> Wiring diagram engine performance 2.0l flex fuel, phev (2 of 8) -> CHARGE PORT LIGHT RING
