Ford C-MAX II (2010-2015) bst pwr vac pump mp sig vpwr vac sen sig Wiring diagram
This page shows the only wiring diagram for the component.bst pwr vac pump mp sig vpwr vac sen sig, which is found in the car Ford C-MAX II (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bst pwr vac pump mp sig vpwr vac sen sig (1 of 1)
13 12 MS CAN- MS CAN+
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE (LEFT REAR OF ENGINE COMPT)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BST PWR VAC PUMP MP SIG VPWR VAC SEN SIG
COMPUTER DATA LINES SYSTEM
EV HS CAN+ EV HS CAN- VAC SENS PWR VAC SEN GND
FUSE 19 FUSE FUSE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC)
LEFT REAR WHEEL SPEED SENSOR (LEFT REAR WHEEL HUB ASSEMBLY)
MP GND BST PWM VBATT
MP SENSE PAS GND
NCA WIRE
PAS SIG 1 VAC PUMP MON PAS SIG 2 PAS SENSEP
RED WIRE
RIGHT FRONT WHEEL SPEED SENSOR (RIGHT FRONT WHEEL HUB ASSEMBLY)
VACRC
VIO WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component: -> Anti-lock brakes circuit (1 of 2) -> BST PWR VAC PUMP MP SIG VPWR VAC SEN SIG
