Ford C-MAX II (2010-2015) (body wiring harness, Wiring diagrams

This page contains all the electrical diagrams for the component. (body wiring harness,, in which he is found in the car Ford C-MAX II (2010-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram (body wiring harness, (1 of 2)

Wiring diagram (body wiring harness, for Ford C-MAX II (2010-2015)

Get access

BLK WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/GRY WIRE BLU/WHT WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE DRIVER DOOR RELEASE LAMP DRIVER DOOR WINDOW CONTROL SWITCH DRIVER MAP POCKET LAMP FLOOR CONSOLE CUP HOLDER AMBIENT LIGHTING LAMP (W/ AMBIENT LIGHTING) GRN/BLU WIRE LAMP (W/O POWER LIFTGATE) LEFT FOOTWELL LAMP (W/ AMBIENT LIGHTING) LID LATCH (W/O POWER LIFTGATE) (BOTTOM CENTER OF LIFTGATE) LIFTGATE/LUGGAGE COMPARTMENT LIFTGATE/LUGGAGE COMPARTMENT LID SWITCH (W/ POWER LIFTGATE) LUGGAGE COMPARTMENT LUGGAGE COMPARTMENT LAMP (W/ POWER LIFTGATE) NCA WIRE PASSENGER DOOR RELEASE LAMP PASSENGER MAP POCKET LAMP REAR FOOTWELL LAMP (W/ AMBIENT LIGHTING) RIGHT EXTERIOR MIRROR RIGHT FOOTWELL LAMP (W/ AMBIENT LIGHTING) VPWR W/ POWER LIFTGATE W/O POWER LIFTGATE WHT/BLU WIRE YEL/ORG WIRE

Go to component: -> Courtesy lamps circuit (3 of 3) -> (BODY WIRING HARNESS,

Wiring diagram (body wiring harness, (2 of 2)

Wiring diagram (body wiring harness, for Ford C-MAX II (2010-2015)

Get access

AUTO DIMMING INTERIOR MIRROR BLK WIRE BLK/VIO WIRE BLK/WHT WIRE BLOWER MOTOR CONTROL MODULE BLU WIRE CIGAR LIGHTER DIRECT CURRENT/ ALTERNATING CURRENT CIGAR (DC/AC) LIGHTER INVERTER FHEV FLOOR CONSOLE CUP REAR HOLDER FOOTWELL AMBIENT LAMP LIGHTING LAMP FUEL DOOR INTERLOCK SWITCH GLASS ROOF DRIVER SIDE PANEL INTERIOR BLIND LAMP MODULE GLOBAL POSITIONING SYSTEM MODULE GLOVE COMPARTMENT LAMP GRN WIRE GRY WIRE HIGH VOLTAGE BATTERY COOLING FAN LEFT REAR LAMP ASSEMBLY LEFT RIGHT FOOTWELL FOOTWELL LAMP LAMP LEFT VANITY MIRROR LAMP OVERHEAD (IF CONSOLE EQUIPPED) SWITCH RAIN ASSEMBLY SENSOR PASSENGER DOOR MODULE (PDM) PASSENGER DOOR RELEASE LAMP PASSENGER POCKET MAP LAMP PASSENGER REAR DOOR MODULE (PRDM) PASSENGER SIDE INTERIOR LAMP REAR INTERIOR LAMP RIGHT FRONT DOOR LOCK SWITCH RIGHT VANITY MIRROR LAMP TELEMATIC CONTROL UNIT MODULE (TCU) VIO WIRE W/ AMBIENT LIGHTING W/ ROOF OPENING PANEL W/O HEATED SEATS W/O ROOF OPENING PANEL WHT WIRE YEL WIRE

Go to component: -> Ground distribution circuit (3 of 4) -> (BODY WIRING HARNESS,
