Ford C-MAX II (2010-2015) battery compartment thermistor 13 Wiring diagram

This page shows the only wiring diagram for the component.battery compartment thermistor 13, which is found in the car Ford C-MAX II (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram battery compartment thermistor 13 (1 of 1)

Wiring diagram battery compartment thermistor 13 for Ford C-MAX II (2010-2015)

Get access

BATTERY COMPARTMENT THERMISTOR 1 BATTERY COMPARTMENT THERMISTOR 10 BATTERY COMPARTMENT THERMISTOR 11 BATTERY COMPARTMENT THERMISTOR 12 BATTERY COMPARTMENT THERMISTOR 13 BATTERY COMPARTMENT THERMISTOR 14 BATTERY COMPARTMENT THERMISTOR 15 BATTERY COMPARTMENT THERMISTOR 16 BATTERY COMPARTMENT THERMISTOR 2 BATTERY COMPARTMENT THERMISTOR 3 BATTERY COMPARTMENT THERMISTOR 4 BATTERY COMPARTMENT THERMISTOR 5 BATTERY COMPARTMENT THERMISTOR 6 BATTERY COMPARTMENT THERMISTOR 7 BATTERY COMPARTMENT THERMISTOR 8 BATTERY COMPARTMENT THERMISTOR 9 BATTERY ENERGY CONTROL MODULE (BECM) (LEFT SIDE OF HIGH VOLTAGE BATTERY COMPT) BLK WIRE BLU/WHT WIRE BRN/BLU WIRE BRN/WHT WIRE GRN/BRN WIRE GRN/RED WIRE GRN/VIO WIRE GRY/YEL WIRE TR RTN TR BREF VIO WIRE VIO/WHT WIRE WHT/GRN WIRE YEL/BLU WIRE YEL/ORG WIRE

Go to component: -> Wiring diagram engine performance 2.0l flex fuel, phev (5 of 8) -> BATTERY COMPARTMENT THERMISTOR 13
