Ford C-MAX II (2010-2015) 45 2 rwd switch rwd ind Wiring diagram

1 13 18 7 MS CAN+ MS CAN- MIRR GND HTD MIRR 13 2 GND VBATT 40 41 3 MS CAN - MS CAN + LOGIC GND 45 2 RWD SWITCH RWD IND BLK WIRE BLK/GRY WIRE BLK/VIO WIRE BLU WIRE BLU/GRY WIRE BODY CONTROL MODULE (LOWER RIGHT SIDE OF DASH) BRN WIRE BRN/BLU WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR MODULE (DDM) FUSE 10 FUSE 4 FUSE 5 GRN/BLU WIRE GRN/VIO WIRE GRY/ORG WIRE HEATED REAR WINDOW ELEMENT HOT AT ALL TIMES LEFT EXTERIOR MIRROR MICRO - NCA WIRE ORG/ WIRE PASSENGER AIR BAG DEACTIVATION (PAD) INDICATOR PASSENGER DOOR MODULE (PDM) REAR JUNCTION BOX (RJB) (BASE OF LEFT "D" PILLAR) REAR WINDOW DEFROST RELAY RED WIRE RIGHT EXTERIOR MIRROR RWDR CTRL VIO/GRN WIRE VIO/ORG WIRE WHT WIRE WHT/ORG WIRE YEL WIRE
