Ford C-MAX II (2010-2015) 13 20 19 fcv hs can+ hs can- Wiring diagram

This page shows the only wiring diagram for the component.13 20 19 fcv hs can+ hs can-, which is found in the car Ford C-MAX II (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram 13 20 19 fcv hs can+ hs can- (1 of 1)

Wiring diagram 13 20 19 fcv hs can+ hs can- for Ford C-MAX II (2010-2015)

Get access

1 2 3 4 GND VBATT VPWR LIN 1 2 3 4 PWR GND 13 20 19 FCV HS CAN+ HS CAN- 2 3 1 LIN VPWR GND ACTIVE GRILLE SHUTTER (LEFT FRONT OF ENGINE COMPT) BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK/YEL WIRE BRN/GRN WIRE CHT COMPUTER DATA LINES SYSTEM COOLING FAN MOTOR (BEHIND RADIATOR) CYLINDER HEAD TEMPERATURE (CHT) SENSOR (TOP OF ENGINE) ENGINE COOLING FAN RELAY FCV FUSE 1 FUSE 2 FUSE 35 GRN/BLU WIRE GRN/RED WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ PCM POWER RELAY ENERGIZED LIN MICRO - NCA WIRE POWERTRAIN CONTROL MODULE (PCM) (FRONT OF LEFT FRONT WHEELWELL) SIG RTN SIGRTN VIO WIRE VIO/BRN WIRE VIO/GRY WIRE WATER COOLANT PUMP 1 (LOWER LEFT FRONT OF ENGINE) WHT WIRE WHT/BLU WIRE YEL WIRE YEL/GRY WIRE

Go to component: -> Cooling fan circuit -> 13 20 19 FCV HS CAN+ HS CAN-
