Ford C-MAX II (2010-2015) 1 5 4 14 vbatt hs can- hs can+ pwr gnd steering angle sensor Wiring diagram

1 5 4 14 VBATT HS CAN- HS CAN+ PWR GND STEERING ANGLE SENSOR 19 20 HS CAN - HS CAN + 2 3 BPP BPS 4 3 BST PWM BST PWR BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) (LOWER RIGHT SIDE OF DASH) BRAKE BOOSTER SOLENOID (LEFT REAR OF ENGINE COMPT) BRAKE BOOSTER TRAVEL SENSOR BRAKE PEDAL POSITION SWITCH (BRAKE PEDAL ASSEMBLY) BRAKE VACUUM PUMP (LOWER LEFT SIDE OF ENGINE) BRN/VIO WIRE COMPUTER DATA LINES SYSTEM FUSE FUSE FUSE FUSE GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/RED WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE HOT AT ALL TIMES HS CAN+ MICRO - MS CAN + POWERTRAIN CONTROL MODULE (PCM) RED WIRE RESTRAINTS CONTROL MODULE (RCM) (UNDER CENTER CONSOLE) SASM SPLY SIG RTN STEERING ANGLE SENSOR MODULE (SASM) STP LT SW VACUUM PUMP CUT-OFF RELAY VACUUM PUMP RELAY VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/ORG WIRE
