Ford C-MAX II (2010-2015) 1 2 3 4 vbatt fan fb fan pwm gnd Wiring diagram

This page shows the only wiring diagram for the component.1 2 3 4 vbatt fan fb fan pwm gnd, which is found in the car Ford C-MAX II (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram 1 2 3 4 vbatt fan fb fan pwm gnd (1 of 1)

Wiring diagram 1 2 3 4 vbatt fan fb fan pwm gnd for Ford C-MAX II (2010-2015)

Get access

1 2 3 4 VBATT FAN FB FAN PWM GND 1 4 8 3 2 FAN PWM FAN FB VBATT HS CAN+ HS CAN- 6 15 1 3 13 5 FAN PWM FAN FB VBATT HS CAN+ HS CAN- GND BATTERY CHARGER CONTROL MODULE (PHEV) (NEAR BATTERY) BATTERY ENERGY CONTROL MODULE (LEFT SIDE OF HIGH VOLTAGE BATTERY COMPT) BLK/BLU WIRE BLK/GRY WIRE BLK/WHT WIRE BLU/WHT WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM FHEV FUSE 17 FUSE 26 FUSE 19 GRY/VIO WIRE HIGH VOLTAGE BATTERY COOLING FAN (LEFT SIDE OF HIGH VOLTAGE BATTERY COMPT) HOT AT ALL TIMES REAR JUNCTION BOX (RJB) (BASE OF LEFT FUSE 18 "D" PILLAR) WHT WIRE WHT/BLU WIRE WHT/GRN WIRE

Go to component: -> Hybrid cooling fan circuit -> 1 2 3 4 VBATT FAN FB FAN PWM GND
