Ford C-MAX II (2010-2015) 1 2 3 4 5 6 run/start hs can + hs can - gnd bts vref btf sig Wiring diagram

1 2 3 4 5 6 RUN/START HS CAN + HS CAN - GND BTS VREF BTF SIG 1 2 3 6 5 BTS SIG BTS VREF GND GND BUCKLE SW 13 12 MS CAN- MS CAN+ ANTI-LOCK BRAKES SYSTEM MODULE (LEFT REAR OF ENGINE COMPT) BATTERY ENERGY CONTROL MODULE (BECM) (LEFT SIDE OF HIGH VOLTAGE BATTERY COMPT) BLK WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE BTS SIG BTS VREF BUCKLE SW CASE GND COMPUTER DATA LINES SYSTEM DRIVER LOWER AIR BAG (LOWER LEFT SIDE OF DASH) DRIVER SAFETY BELT BUCKLE SWITCH (IN DRIVER SEAT BELT BUCKLE ASSEMBLY) DRIVER SAFETY BELT RETRACTOR PRETENSIONER (BASE OF DRIVER "B" PILLAR) DRIVER SEAT POSITION ENS FHEV GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRY WIRE GRY/BLU WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE INSTRUMENT PANEL CLUSTER (IPC) LEFT "C" PILLAR SIDE IMPACT SENSOR (BASE OF LEFT "C"PILLAR) NCA WIRE OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM) (UNDER FRONT PASSENGER'S SEAT) PASSENGER AIR BAG (RIGHT SIDE OF DASH) PASSENGER SAFETY BELT BUCKLE (IN PASSENGER SEAT BELT BUCKLE ASSEMBLY) PASSENGER SAFETY BELT LOAD LIMITING RETRACTOR (BASE OF RIGHT "B" PILLAR) PASSENGER SAFETY BELT RETRACTOR PRETENSIONER (BASE OF PASSENGER "B" PILLAR) PASSENGER SEAT POSITION RESTRAINTS CONTROL MODULE (RCM) (UNDER CENTER CONSOLE) RIGHT "C" PILLAR SIDE IMPACT SENSOR (BASE OF RIGHT "C"PILLAR) SENSOR (UNDER DRIVER SEAT, ON SLIDE RAIL) SENSOR (UNDER PASSENGER SEAT, ON SLIDE RAIL) SHORTING BAR STAGE 1 STAGE 2 VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/ORG WIRE YEL WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE
