Active bodyworks circuit for Ford Bronco VI (2020-2024)

Active bodyworks circuit

Get access

2.7L TURBO BATTERY JUNCTION BOX (BCMC) BLK/GRY WIRE BLU/ORG WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM FUSE 8 GENERATOR GRN/BLU WIRE GRY WIRE HOT W/ PCM POWER RELAY ENERGIZED INSTRUMENT PANEL CLUSTER (IPC) LIN LOWER ACTIVE GRILLE SHUTTER ACTUATOR POWERTRAIN CONTROL MODULE (PCM) S100 (2.3L TURBO) S101 (2.7L TURBO) UPPER ACTIVE GRILLE SHUTTER ACTUATOR VIO/GRY WIRE WHT/GRN WIRE YEL/ORG WIRE
