Ford Bronco VI (2020-2024) rod pressure sensor rtn rod pressure sensor Wiring diagram

This page shows the only wiring diagram for the component.rod pressure sensor rtn rod pressure sensor, which is found in the car Ford Bronco VI (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram rod pressure sensor rtn rod pressure sensor (1 of 1)

Wiring diagram rod pressure sensor rtn rod pressure sensor for Ford Bronco VI (2020-2024)

Get access

BATTERY JUNCTION BOX (BJB) BLK/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CHASSIS CONTROL MODULE (CHCM) COMPUTER DATA LINES SYSTEM DRIVE PISTON VALVE + DRIVE ROD DRIVE ROD VALVE + FUSE 158 FUSE 66 GRN/WHT WIRE GRY/BLU WIRE GRY/ORG WIRE HOT AT ALL TIMES HOT W/ RUN/ START RELAY ENERGIZED LEFT FRONT STABILIZER BAR DISCONNECT PISTON PRESSURE SENSOR PISTON PRESSURE SENSOR PWR PISTON PRESSURE SENSOR RTN RIGHT FRONT STABILIZER BAR DISCONNECT ROD PRESSURE ROD PRESSURE SENSOR PWR ROD PRESSURE SENSOR RTN ROD PRESSURE SENSOR SENSOR SENSOR PWR SENSOR RTN SWAY BAR DISCONNECT RELAY VALVE VPWR WHT/ORG WIRE YEL/GRY WIRE YEL/ORG WIRE

Go to component: -> Electronic suspension circuit -> ROD PRESSURE SENSOR RTN ROD PRESSURE SENSOR
