Ford Bronco VI (2020-2024) right rear door window control switch Wiring diagram
This page shows the only wiring diagram for the component.right rear door window control switch, which is found in the car Ford Bronco VI (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear door window control switch (1 of 1)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DEMAND LP/ BATT SAVE (FET)
DRIVER DOOR
DRIVER DOOR MODULE (DDM) (LEFT KICK PANEL)
DRIVER DOOR WINDOW REGULATOR MOTOR
FUSE 182
FUSE 183
FUSE 3
GRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
ILLUM
LEFT FRONT DOOR LOCK SWITCH
LEFT REAR DOOR WINDOW CONTROL SWITCH
LEFT REAR DOOR WINDOW REGULATOR MOTOR
LF WINDOW DOWN
LF WINDOW UP
LIN
LR WINDOW DOWN
LR WINDOW UP
MS CAN +
RIGHT REAR DOOR WINDOW CONTROL SWITCH
RTN
SW RTN
VBATT
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/GRN WIRE
Go to component: -> Power windows circuit (1 of 2) -> RIGHT REAR DOOR WINDOW CONTROL SWITCH
