Ford Bronco VI (2020-2024) master window control switch Wiring diagrams
This page contains all the electrical diagrams for the component. master window control switch, in which he is found in the car Ford Bronco VI (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram master window control switch (1 of 2)
360 CAMERA
AAT
AIR CONDITIONING SYSTEM
BATTERY JUNCTION BOX (BJB)
BLISS IND
BLK WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DRIVER DOOR MODULE (DDM)
EXTERIOR MIRROR CONTROL SWITCH
FUSE 182
FUSE 3
GRN/BLU WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
LEFT EXTERIOR MIRROR
LEFT REAR DOOR WINDOW CONTROL SWITCH
LIN
MASTER WINDOW CONTROL SWITCH
MIRROR COMMON
MIRROR LH/RH
MIRROR SENS/ BLISS GND
MIRROR UP/DWN
MS CAN +
NAVIGATION SYSTEM
PUDDLE
PUDDLE LAMP
RTN
SPOT
VBATT
VIO/BRN WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VPWR
WHT/GRN WIRE
Go to component -> Power mirrors circuit (1 of 2) -> MASTER WINDOW CONTROL SWITCH
Wiring diagram master window control switch (2 of 2)
BLK/WHT WIRE
BLU/GRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
EXTERIOR MIRROR CONTROL SWITCH
GRY WIRE
GRY/ORG WIRE
GRY/YEL WIRE
ILLUM
LIN
LR WINDOW DOWN
LR WINDOW UP
MASTER WINDOW CONTROL SWITCH
MS CAN +
PASSENGER DOOR MODULE (PDM)
PASSENGER DOOR WINDOW REGULATOR MOTOR
PASSENGER DOOR)
RF WINDOW DOWN
RF WINDOW UP
RIGHT FRONT DOOR LOCK SWITCH
RIGHT REAR DOOR
RIGHT REAR DOOR WINDOW REGULATOR MOTOR
RR WINDOW DOWN
RR WINDOW UP
RTN
SW RTN
VBATT
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/GRN WIRE
YEL/ORG WIRE
Go to component -> Power windows circuit (2 of 2) -> MASTER WINDOW CONTROL SWITCH
