Ford Bronco VI (2020-2024) ecall switch Wiring diagram
This page shows the only wiring diagram for the component.ecall switch, which is found in the car Ford Bronco VI (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ecall switch (1 of 1)
ANT-SDARS SIG
ANTENNA SPLITTER
AUDIO CONTROL MODULE (ACM)
AUDIO OUT -
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BODY CONTROL MODULE (BCM)
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CELLPHONE PRIMARY +
CELLPHONE SECONDARY + GPS ANT +
COAX
COMPUTER DATA LINES SYSTEM
E-CALL +
E-CALL LIGHT
ECALL SWITCH
ECG/TCU ENET -
ENS
FUSE 20
FUSE 46
GPS ANTENNA
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
ILLUM
LEFT INTERIOR CELLPHONE ANTENNA
MIC -
MICROPHONE
OVERHEAD CONSOLE
PHONE/VOICE -
RIGHT INTERIOR CELLPHONE ANTENNA
RTN
SHIELD
SOUND SYSTEMS
SUPPLEMENTAL RESTRAINTS SYSTEM
SYNC MODULE (APIM)
TELEMATICS CONTROL UNIT (TCU) MODULE
VBATT
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/O SDARS
WHT/GRN WIRE
WHT/ORG WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component: -> Telematics circuit -> ECALL SWITCH
