Ford Bronco VI (2020-2024) app rtn 2 Wiring diagram
This page shows the only wiring diagram for the component.app rtn 2, which is found in the car Ford Bronco VI (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram app rtn 2 (1 of 1)
2.7L TURBO
9 VREF 2
ACCELERATOR PEDAL POSITION (APP) SENSOR
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
APP 1
APP 2
APP RTN 1
APP RTN 2
APP VREF 2
APPV REF 1
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BOO
BPP
BPS
BRAKE PEDAL POSITION (BPP) SWITCH
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
CLUTCH MASTER CYLINDER PUSH ROD POSITION SENSOR
COMPUTER DATA LINES SYSTEM
ELECTRONIC THROTTLE CONTROL (ETC)
ETC REF
ETC RTN
FUSE 13
FUSE 25
FUSE 36
FUSE 44
GRN/BLU WIRE
GRN/ORG WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ RUN/START 1 RELAY ENERGIZED
HOT W/ RUN/START RELAY ENERGIZED
MICRO -
OSS 9 VREF 1
POWERTRAIN CONTROL MODULE (PCM)
SIG RTN
TACM+
TR GND
TRP 1
TRP 2
TSS
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VREF
WHT WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component: -> Cruise control circuit (1 of 2) -> APP RTN 2
