Ford Bronco VI (2020-2024) anti-theft alarm horn relay Wiring diagrams
This page contains all the electrical diagrams for the component. anti-theft alarm horn relay, in which he is found in the car Ford Bronco VI (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
anti-theft alarm horn relay wiring diagram (1 of 3)
ANT
ANTI-THEFT ALARM HORN RELAY
BLU/BRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN/GRN WIRE
FUSE 31
FUSE 6
GRN WIRE
GRN/BLU WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/VIO WIRE
HALF BRIDGE
HOT AT ALL TIMES
INT 1 ANTENNA HI (HB)
INT 1 ANTENNA LO (HB)
INT 2 ANTENNA HI (HB)
INT 2 ANTENNA LO (HB)
K LINE
KEYLESS VEHICLE CENTER ANTENNA
LEFT REAR KEYLESS VEHICLE ANTENNA
LIFTGATE INTELLIGENT ACCESS (IA) ANTENNA
MICRO -
PASSENGER DOOR)
PROTECT 1 ANTENNA HI (HB)
PROTECT 1 ANTENNA LO (HB)
RED WIRE
RIGHT FRONT EXTERIOR DOOR HANDLE
RIGHT REAR KEYLESS VEHICLE ANTENNA
RTN
VIO/ORG WIRE
VREF
WHT WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
Go to component -> Anti-theft circuit (3 of 5) -> ANTI-THEFT ALARM HORN RELAY
anti-theft alarm horn relay wiring diagram (2 of 3)
2.7L TURBO
ACCESSORY DELAY RELAY
AIR CONDITIONING (A/C) COMPRESSOR
ALL DOOR LOCK (FET)
ALL DOOR UNLOCK (FET)
ALL WHEEL DRIVE (AWD) MODULE
ANTI-THEFT ALARM HORN RELAY
AUTO DIMMING INTERIOR MIRROR
BACK LTG (FET)
BATTERY JUNCTION BOX (BJB)
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BSI (FET)
CABIN HEATER COOLANT PUMP
COOLING FAN RELAY 1
COOLING FAN RELAY 2
DRIVER DOOR UNLOCK (FET)
ELECTRIC COOLANT PUMP
EXTERIOR MIRROR CONTROL SWITCH
FROM BODY CONTROL MODULE (BCM) (DIAGRAM 2 OF 6)
FROM FUSE 7 (DIAGRAM 1 OF 6)
FUSE 19
FUSE 2
FUSE 20
FUSE 21
FUSE 3
FUSE 34
FUSE 36
FUSE 37
FUSE 54
FUSE 6
FUSE 8
GRN WIRE
GRN/RED WIRE
GRY WIRE
HEADLAMP SWITCH
IN-VEHICLE TEMPERATURE/ HUMIDITY SENSOR
LANE DEPARTURE WARNING (LDW) MODULE
LOWER ACTIVE GRILLE SHUTTER ACTUATOR
MICRO -
OIL PRESSURE CONTROL SOLENOID
OVERHEAD CONSOLE
PARKING AID MODULE (PAM)
PCM WAKE UP (FET)
RCM PWR (FET)
RED WIRE
RUN/ START RELAY
TAILGATE LOCK (FET)
TAILGATE UNLOCK (FET)
TELEMATICS CONTROL UNIT (TCU) MODULE
TO DIRECT CURRENT/ ALTERNATING CURRENT (DC/AC) INVERTER (DIAGRAM 3 OF 6)
TO PUSH BUTTON START IGNITION SWITCH (DIAGRAM 4 OF 6)
TO WIRELESS ACCESSORY CHARGING MODULE (WACM) (DIAGRAM 4 OF 6)
TO WIRELESS CHARGE SIGNAL OUTPUT (FET) (DIAGRAM 4 OF 6)
TRANSMISSION FLUID HEATER COOLANT CONTROL VALVE
TURBOCHARGER BYPASS (TCBY) VALVE
VACUUM SOLENOID VALVE (VSV)
VARIABLE OIL PUMP
VIO/ORG WIRE
WHT WIRE
Go to component -> Power distribution circuit (5 of 6) -> ANTI-THEFT ALARM HORN RELAY
anti-theft alarm horn relay wiring diagram (3 of 3)
ANT
ANTI-THEFT ALARM HORN RELAY
BLU/BRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN/GRN WIRE
FUSE 31
FUSE 6
GRN WIRE
GRN/BLU WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/VIO WIRE
HALF BRIDGE
HOT AT ALL TIMES
INT 1 ANTENNA HI (HB)
INT 1 ANTENNA LO (HB)
INT 2 ANTENNA HI (HB)
INT 2 ANTENNA LO (HB)
K LINE
KEYLESS VEHICLE CENTER ANTENNA
LEFT REAR KEYLESS VEHICLE ANTENNA
LIFTGATE INTELLIGENT ACCESS (IA) ANTENNA
MICRO -
PASSENGER DOOR)
PROTECT 1 ANTENNA HI (HB)
PROTECT 1 ANTENNA LO (HB)
RED WIRE
RIGHT FRONT EXTERIOR DOOR HANDLE
RIGHT REAR KEYLESS VEHICLE ANTENNA
RTN
VIO/ORG WIRE
VREF
WHT WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
Go to component -> Power door locks circuit (3 of 5) -> ANTI-THEFT ALARM HORN RELAY
