Ford Bronco VI (2020-2024) antenna splitter Wiring diagrams
This page contains all the electrical diagrams for the component. antenna splitter, in which he is found in the car Ford Bronco VI (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram antenna splitter (1 of 5)
AM/FM
AM/FM ANTENNA AMPLIFIER
ANT
ANT-SDARS SIG
ANTENNA SPLITTER
AUDIO CONTROL MODULE (ACM)
BLK/GRY WIRE
BLU/GRY WIRE
BRN WIRE
BRN/BLU WIRE
COAX
COMPUTER DATA LINES SYSTEM
DRDL TX +
GPS
GPS ANTENNA
GPS W/ BUILT IN NAVIGATION
GPS W/O BUILT IN NAVIGATION
GRN/BLU WIRE
GRN/BRN WIRE
GRY/VIO WIRE
INSTRUMENT PANEL CENTER SPEAKER
IP CEN SPKR +
LEFT KICK PANEL SPEAKER
LEFT REAR SPEAKER
LR SPKR
RIGHT REAR SPEAKER
RR SPKR
TELEMATICS CONTROL UNIT (TCU) MODULE
VIO/ORG WIRE
VIO/RED WIRE
W/O SDARS
WHT WIRE
WHT/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Navigation circuit, 10 speakers (1 of 4) -> ANTENNA SPLITTER
Wiring diagram antenna splitter (2 of 5)
AM/FM
AM/FM ANTENNA AMPLIFIER
ANT
ANT-SDARS SIG
ANTENNA SPLITTER
AUDIO CONTROL MODULE (ACM)
BLK/GRY WIRE
BLU WIRE
BRN/GRN WIRE
COAX
COMPUTER DATA LINES SYSTEM
DRDL TX +
GPS
GPS ANTENNA
GPS W/ BUILT IN NAVIGATION
GPS W/O BUILT IN NAVIGATION
GRN/BLU WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/VIO WIRE
LEFT INSTRUMENT PANEL SPEAKER
LEFT KICK PANEL SPEAKER
LF SPKR
LR SPKR
RF SPKR
RIGHT KICK PANEL SPEAKER
RR SPKR
TELEMATICS CONTROL UNIT (TCU) MODULE
VIO/GRY WIRE
VIO/RED WIRE
W/O SDARS
WHT/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Navigation circuit, 6 speakers (1 of 4) -> ANTENNA SPLITTER
Wiring diagram antenna splitter (3 of 5)
AM/FM
AM/FM ANTENNA AMPLIFIER
ANT
ANT-SDARS SIG
ANTENNA SPLITTER
AUDIO CONTROL MODULE (ACM)
BLK/GRY WIRE
BLU/GRY WIRE
BRN WIRE
BRN/BLU WIRE
COAX
COMPUTER DATA LINES SYSTEM
DRDL TX +
GPS
GPS ANTENNA
GPS W/ BUILT IN NAVIGATION
GPS W/O BUILT IN NAVIGATION
GRN/BLU WIRE
GRN/BRN WIRE
GRY/VIO WIRE
INSTRUMENT PANEL CENTER SPEAKER
IP CEN SPKR +
LEFT KICK PANEL SPEAKER
LEFT REAR SPEAKER
LR SPKR
RIGHT REAR SPEAKER
RR SPKR
TELEMATICS CONTROL UNIT (TCU) MODULE
VIO/ORG WIRE
VIO/RED WIRE
W/O SDARS
WHT WIRE
WHT/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Radio circuit, 10 speakers (1 of 4) -> ANTENNA SPLITTER
Wiring diagram antenna splitter (4 of 5)
AM/FM
AM/FM ANTENNA AMPLIFIER
ANT
ANT-SDARS SIG
ANTENNA SPLITTER
AUDIO CONTROL MODULE (ACM)
BLK/GRY WIRE
BLU WIRE
BRN/GRN WIRE
COAX
COMPUTER DATA LINES SYSTEM
DRDL TX +
GPS
GPS ANTENNA
GPS W/ BUILT IN NAVIGATION
GPS W/O BUILT IN NAVIGATION
GRN/BLU WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/VIO WIRE
LEFT INSTRUMENT PANEL SPEAKER
LEFT KICK PANEL SPEAKER
LF SPKR
LR SPKR
RF SPKR
RIGHT KICK PANEL SPEAKER
RR SPKR
TELEMATICS CONTROL UNIT (TCU) MODULE
VIO/GRY WIRE
VIO/RED WIRE
W/O SDARS
WHT/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Radio circuit, 6 speakers (1 of 4) -> ANTENNA SPLITTER
Wiring diagram antenna splitter (5 of 5)
ANT-SDARS SIG
ANTENNA SPLITTER
AUDIO CONTROL MODULE (ACM)
AUDIO OUT -
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BODY CONTROL MODULE (BCM)
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CELLPHONE PRIMARY +
CELLPHONE SECONDARY + GPS ANT +
COAX
COMPUTER DATA LINES SYSTEM
E-CALL +
E-CALL LIGHT
ECALL SWITCH
ECG/TCU ENET -
ENS
FUSE 20
FUSE 46
GPS ANTENNA
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
ILLUM
LEFT INTERIOR CELLPHONE ANTENNA
MIC -
MICROPHONE
OVERHEAD CONSOLE
PHONE/VOICE -
RIGHT INTERIOR CELLPHONE ANTENNA
RTN
SHIELD
SOUND SYSTEMS
SUPPLEMENTAL RESTRAINTS SYSTEM
SYNC MODULE (APIM)
TELEMATICS CONTROL UNIT (TCU) MODULE
VBATT
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/O SDARS
WHT/GRN WIRE
WHT/ORG WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Telematics circuit -> ANTENNA SPLITTER
