Ford Bronco VI (2020-2024) 360 camera enable Wiring diagram

This page shows the only wiring diagram for the component.360 camera enable, which is found in the car Ford Bronco VI (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram 360 camera enable (1 of 1)

Wiring diagram 360 camera enable for Ford Bronco VI (2020-2024)

Get access

360 CAMERA ENABLE AUDIO CONTROL PANEL BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/GRY WIRE CAMERA CAMERA ENABLE SW COMPUTER DATA LINES SYSTEM ENABLE SW FRONT PARKING AID CAMERA FRONT VIDEO + FUSE 22 GRN/ORG WIRE GRY/BLU WIRE HOT W/ RUN/START RELAY 2 ENERGIZED IMAGE PROCESSING MODULE B (IPMB) LEFT EXTERIOR MIRROR LEFT VIDEO + REAR PARKING AID CAMERA REAR VIDEO - RIGHT EXTERIOR MIRROR RIGHT VIDEO + SYNC MODULE (APIM) VIDEO OUT VIDEO+ VPWR WHT/GRN WIRE

Go to component: -> Rear camera circuit -> 360 CAMERA ENABLE
