Ford Bronco V (1992-1996) courtesy lamps input wiring diagram

"ANTI-THEFT" INDICATOR ALARM INDICATOR OUTPUT ANTI-THEFT CONTROLLER MODULE (BEHIND LEFT SIDE OF I/P) BATTERY BLK WIRE BLK/ORG WIRE BLK/WHT (OR BLK/LT BLU) WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CIRCUIT BREAKER 12 COURTESY LAMP DIODE INTERIOR LIGHTS SYSTEM (COURTESY LIGHTS) COURTESY LAMPS INPUT CREW CAB ONLY DISARM INPUT DK BLU WIRE DK BLU/LT GRN WIRE DK BLU/ORG WIRE DK GRN/PPL WIRE DK GRN/WHT WIRE DOOR AJAR DOOR LOCKS SYSTEM (REMOTE KEYLESS ENTRY) EXTERIOR LAMPS OUTPUT FUSE PANEL FUSE 6 GROUND GRY WIRE HEADLAMPS ENABLE HEADLIGHTS SYSTEM HORN ENABLE OUTPUT HORNS SYSTEM HOT AT ALL TIMES HOT AT ALL TIMES FUSE PANEL FUSE 8 HOT IN ACCY OR RUN IGNITION INPUT IGNITION SWITCH INSTRUMENT CLUSTER INTERIOR LIGHTS SYSTEM (COURTESY LIGHTS) KEY CYLINDER INPUT KEY CYLINDER SENSOR LEFT FRONT COURTESY LAMP SWITCH (ON FRONT OF DOOR JAMB) LEFT FRONT DOOR DISARM SWITCH (IN LEFT FRONT DOOR) LIFTGATE JAMB SW INPUT LOCK ALL DOORS LOCK DOORS LOCK OFF LT BLU WIRE LT GRN WIRE LT GRN/PPL WIRE LT GRN/YEL WIRE NCA WIRE ORG/ WIRE PNK WIRE PNK/BLK WIRE PNK/ORG WIRE RED WIRE RED/BLK WIRE RED/LT BLU WIRE RED/ORG WIRE RED/PNK WIRE REMOTE KEYLESS ENTRY MODULE RIGHT FRONT COURTESY LAMP SWITCH (ON FRONT OF DOOR JAMB) RIGHT FRONT DOOR DISARM SWITCH (IN RIGHT FRONT DOOR) RIGHT REAR COURTESY LAMP SWITCH (LOWER REAR OF DOOR) RUN WIRE RUN/ACCY POWER SPEED CONTROL/ HORN SWITCH ASSEMBLY (CRUISE CONTROL SYSTEM) STARTER MOTOR OUTPUT STARTING SYSTEM UNLOCK ALL DOORS UNLOCK DOORS UNLOCK DRIVER'S DOOR WARNING SYSTEM (WARNING CHIME) YEL WIRE YEL/LT GRN WIRE
