Ford Bronco V (1992-1996) ambient temp sensor feed Wiring diagram
This page shows the only wiring diagram for the component.ambient temp sensor feed, which is found in the car Ford Bronco V (1992-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ambient temp sensor feed (1 of 1)
AMBIENT TEMP SENSOR FEED
AMBIENT TEMPERATURE SENSOR (RIGHT FRONT OF ENGINE COMPT)
BATTERY SAVER INPUT
BLK WIRE
BLK/LT BLU WIRE
COMPASS
COURTESY LAMP INPUT
CRUISE CONTROL SERVO/AMPLIFIER ASSEMBLY
DK BLU WIRE
DK BLU/YEL WIRE
GROUND
GRY WIRE
GRY/BLK WIRE
HOT IN RUN FUSE 18
IGN (HOT IN RUN)
INSTRUMENT CLUSTER
INSTRUMENT ILLUM INPUT
INTERIOR FUSE PANEL: I/P
LT BLU/RED WIRE
LT GRN/YEL WIRE
MICROPROCESSOR
OVERHEAD CONSOLE
POWERTRAIN CONTROL MODULE
PPL
PROGRAMMABLE SPEEDOMETER/ ODOMETER MODULE
THERMOMETER
VEHICLE SPEED INPUT
VEHICLE SPEED OUTPUT
WHT WIRE
WHT/PPL WIRE
YEL WIRE
Go to component: -> Overhead console circuit -> AMBIENT TEMP SENSOR FEED
