Ford Bronco Sport I (2020-2024) Charging circuit

2.0L TURBO ACTIVE GRILLE SHUTTER BATTERY BATTERY MONITORING SENSOR BLK WIRE BLU WIRE BODY CONTROL MODULE (BCM) COMPUTER DATA LINES SYSTEM GENERATOR GRN/BLU WIRE INSTRUMENT PANEL CLUSTER (IPC) MODULE MEGA FUSE NCA WIRE POWER DISTRIBUTION SYSTEM POWERTRAIN CONTROL MODULE (PCM) RED WIRE STARTER MOTOR VIO/BRN WIRE VIO/WHT WIRE WHT WIRE WHT/GRN WIRE
