Instrument illumination circuit for Ford Bronco Sport I (2020-2024)

BACK LTG LED (FET) BLK/BLU WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/GRY WIRE BODY CONTROL MODULE (BCM) BRN WIRE CENTER CONSOLE COMPUTER DATA LINES SYSTEM DOME LAMP ELECTRONIC PARK BRAKE SWITCH FUSE 3 GRN/BLU WIRE GRY/BLU WIRE HIGH CURRENT BATTERY JUNCTION BOX (BJB) HOT AT ALL TIMES ILLUM INSTRUMENT PANEL CLUSTER (IPC) MODULE IP RELEASE KEYPAD A KEYPAD B KEYPAD C KEYPAD ILLUM (FET) MEDIA GND MEDIA HUB MEDIA PWR MICRO - OVERHEAD CONSOLE PASSENGER AIR BAG DEACTIVATION (PAD) INDICATOR PUSH BUTTON START IGNITION SWITCH PWR ROOF OPENING PANEL SWITCH SUNSHADE SWITCH SWITCH SYNC MODULE (APIM) (CENTER OF DASH) VIO/GRN WIRE VIO/GRY WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

1/2 3/4 5/6 7/8 9/0 BATTERY JUNCTION BOX (BJB) BLK/BLU WIRE BLK/VIO WIRE BLU/GRY WIRE BODY CONTROL MODULE (BCM) BRN WIRE CLOCKSPRING DOWNSHIFT PADDLE SWITCH FUSE 12 FUSE 93 GRN/RED WIRE GRY/BLU WIRE GRY/RED WIRE HEADLAMP SWITCH HOT AT ALL TIMES KEYLESS ENTRY KEYPAD LEFT STEERING WHEEL SWITCH LIFTGATE LOGIC NCA WIRE RIGHT STEERING WHEEL SWITCH STEERING COLUMN CONTROL MODULE (SCCM) UPSHIFT PADDLE SWITCH VBATT VIO/GRN WIRE VIO/GRY WIRE WHT/GRN WIRE YEL/GRN WIRE

BLK/GRY WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/GRN WIRE BODY CONTROL MODULE (BCM) BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR MODULE (DDM) DRIVER DOOR WINDOW CONTROL SWITCH FUSE 14 FUSE 7 GRN/BLU WIRE GRN/BRN WIRE GRY/ORG WIRE HOT AT ALL TIMES ILLUM LEFT FRONT DOOR LOCK SWITCH LEFT REAR DOOR WINDOW SWITCH MS CAN + ONE TOUCH UP/DOWN ONE- TOUCH DOWN PASSENGER DOOR MODULE (PDM) PASSENGER DOOR WINDOW CONTROL SWITCH RIGHT FRONT DOOR LOCK SWITCH RIGHT REAR DOOR WINDOW SWITCH RTN SW ILLUM VBATT VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE WHT/BLU WIRE WHT/RED WIRE
