Passive anti-theft circuit for Ford Bronco Sport I (2020-2024)

ANT BLK/BLU WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) BRN/GRN WIRE COMPUTER DATA LINES SYSTEM GRN/BLU WIRE HALF BRIDGE HIGH CURRENT BATTERY JUNCTION BOX (BJB) HOT AT ALL TIMES HS CAN+ INSTRUMENT PANEL CLUSTER (IPC) MODULE INT 1 ANTENNA HI (HB) INT 1 ANTENNA LO (HB) INT 2 ANTENNA HI (HB) INT 2 ANTENNA LO (HB) KEYLESS ENTRY FRONT ANTENNA KEYLESS ENTRY REAR ANTENNA LIN 1 LOGIC GND MEGA FUSE MICRO - PASSIVE ANTI-THEFT SYSTEM (PATS) TRANSCEIVER PCM WAKE PCM WAKEUP (FET) POWERTRAIN CONTROL MODULE (PCM) PROTECT 1 ANTENNA HI (HB) PROTECT 1 ANTENNA LO (HB) PWR VIO/ORG WIRE WHT WIRE WHT/GRN WIRE WHT/ORG WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/RED WIRE
