Interior light circuit for Ford Aspire I (1993-1997)

Interior light circuit

Get access

BLK WIRE BLU WIRE DASH FUSE BOX (LEFT SIDE OF I/P) DOME LAMP HEAD OFF PARK HEADLAMP SWITCH HEATER- A/C CONTROL UNIT HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT PANEL DIMMING RHEOSTAT JOINT CONNECTOR LEFT FRONT DOOR SWITCH LIFTGATE SWITCH LT BLU/RED WIRE LUGGAGE COMPARTMENT SWITCH ASSEMBLY MULTI- FUNCTION SWITCH OFF ON OFF ON DOOR PARKING LAMPS RELAY (RIGHT FRONT OF ENGINE) RADIO REAR WINDOW DEFROSTER/ FOG LAMP SWITCH RADIO RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT FRONT DOOR SWITCH ROOM FUSE STOP FUSE TAIL FUSE TRANSMISSION RANGE ILLUMINATION (W/ A/T ONLY) W/ PREMIUM SOUND W/O PREMIUM SOUND WARNING CHIME MODULE (BEHIND LEFT SIDE OF I/P) WHT WIRE YEL WIRE
