Headlight circuit, with drl for Ford Aspire I (1993-1997)
Headlight circuit, with drl
15 11 (1996) (1995)
18 5 (1996) (1995) (1995) (1996)
BLK WIRE
BLU WIRE
DASH FUSE BOX (LEFT SIDE OF I/P)
DAYTIME RUNNING LAMP RELAY (BEHIND I/P, AT LEFT COWL PANEL)
DAYTIME RUNNING LAMP RESISTOR (CENTER REAR OF ENGINE COMPT)
FLASH TO PASS SWITCH
FOG LAMP RELAY (LEFT REAR OF ENGINE COMPARTMENT)
FOG LAMP SWITCH
GRN WIRE
GRN/YEL WIRE
HEADLAMP DIMMER SWITCH
HEADLAMPS RELAY (LEFT FRONT OF ENGINE COMPT)
HI BEAM INDICATOR
HOT AT ALL TIMES
HOT IN RUN
INSTRUMENT CLUSTER
JOINT CONNECTOR
LEFT FOG LAMP
LEFT HEADLAMP
LT GRN WIRE
MULTI- FUNCTION SWITCH
NCA WIRE
OFF ON
ON OFF
PARK HEAD OFF HI LO HEADLAMP SWITCH
PARKING BRAKE SWITCH (BELOW REAR OF CONSOLE)
POWERTRAIN CONTROL MODULE (BEHIND LEFT SIDE OF I/P)
REAR WINDOW DEFROSTER/ FOG LAMP LAMP SWITCH
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RIGHT FOG LAMP
RIGHT HEADLAMP
WARNING CHIME MODULE (BEHIND LEFT SIDE OF I/P)
WHT WIRE
YEL WIRE
