Ground distribution circuit for Ford Aspire I (1993-1997)

Ground distribution circuit (1 of 2)

Get access

A/C CONDENSER FAN SWITCH ABS MAIN RELAY ANTI-LOCK BRAKE (ABS) HYDRAULIC ACTUATOR UNIT BLK WIRE BLOWER MOTOR RELAY BRAKE FLUID LEVEL SWITCH CIGAR LIGHTER CLUTCH PEDAL POSITION (CCP) SWITCH #1 CONDENSER FAN MOTOR COOLING FAN MOTOR DATA LINK CONNECTOR (DLC) FLASHER MODULE FOG LAMP RELAY GRY WIRE HEATER- A/C CONTROL UNIT IGNITION CONTROL MODULE (ICM) SHIELD INSTRUMENT CLUSTER INSTRUMENT PANEL DIMMING RHEOSTAT JOINT CONNECTOR LEFT FOG LAMP LEFT FRONT PARKING LAMP LEFT FRONT SIDE MARKER LAMP LEFT FRONT TURN SIGNAL LAMP LEFT HEADLAMP M/T ONLY MAIN RELAY MULTI- FUNCTION SWITCH POWER- TRAIN CONTROL MODULE (PCM) RIGHT FOG LAMP RIGHT FRONT PARKING LAMP RIGHT FRONT SIDE MARKER LAMP RIGHT FRONT TURN SIGNAL LAMP RIGHT HEADLAMP WARNING CHIME MODULE WINDSHIELD WASHER PUMP

Get access

AIR BAG DIAGNOSTIC MODULE ANTI- LOCK BRAKE (ABS) CONTROL MODULE BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/LT GRN WIRE GRY WIRE HIGH MOUNT STOP LAMP IGNITION CONTROL MODULE (ICM) IGNITION CONTROL MODULE (ICM) SHIELD INERTIA FUEL SHUTOFF (IFS) SWITCH JOINT CONNECTOR LEFT FRONT BRAKE SENSOR SHIELD LEFT LICENSE LAMP LEFT REAR BRAKE SENSOR SHIELD LEFT REAR LAMP M/T ONLY MASS AIR FLOW (MAF SENSOR) OXYGEN SENSOR SHIELD PARK RANGE SWITCH PARK/ NEUTRAL POSITION SWITCH POWER- TRAIN CONTROL MODULE (PCM) REAR WINDOW DEFROSTER REAR WINDOW DEFROSTER RELAY RIGHT FRONT BRAKE SENSOR SHIELD RIGHT LICENSE LAMP RIGHT REAR BRAKE SENSOR SHIELD RIGHT REAR LAMP SEAT BELT SWITCH SHIFT LOCK ACTUATOR SHORTING CONNECTOR
