Computer data lines for Ford Aspire I (1993-1997)
Computer data lines
14 13 6 7 12 15 DLC DLC DLC VSS VPWR FPR
AIR BAG DIAGNOSTIC MODULE (BEHIND FRONT OF CONSOLE)
ANTI-LOCK BRAKE CONTROL MODULE (BEHIND LEFT SIDE OF I/P)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
CANISTER PURGE SOLENOID (TOP LEFT SIDE OF ENGINE)
CLOCKSPRING ASSEMBLY (TOP OF STEERING COLUMN)
DATA LINK CONNECTOR
EGR CONTROL SOLENOID (CENTER REAR OF ENG COMPT)
EGR VENT SOLENOID (CENTER REAR OF ENG COMPT)
FRONT HARNESS, NEAR BREAK-OUT TO IGNITION CONTROL MODULE)
FUEL INJECTORS
FUEL PUMP RELAY (BEHIND I/P, AT LEFT COWL)
GRN/BLK WIRE
GRN/ORG WIRE
GRN/RED WIRE
HORN RELAY (BEHIND I/P, AT LEFT COWL)
IDLE AIR CONTROL VALVE (TOP LEFT REAR OF ENGINE)
IGNITION CONTROL MODULE (LEFT SIDE OF ENG COMPT)
INSTRUMENT CLUSTER
J/C
MAIN RELAY (BEHIND I/P, AT LEFT COWL)
MASS AIR FLOW (MAF) SENSOR (IN AIR INTAKE ASSEMBLY)
NCA WIRE
NO.1
NO.2 NO.3
NO.4
POWERTRAIN CONTROL MODULE (BEHIND LEFT SIDE OF I/P)
RED/GRN WIRE
TACH
VPWR
WHT WIRE
WHT/BLK WIRE
WHT/YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
