Heater circuit for Ford Aspire I (1993-1997)
Heater circuit
BLK WIRE
BLOWER C.B.
BLOWER MOTOR
BLOWER MOTOR RELAY (LEFT FRONT OF ENGINE COMPARTMENT)
BLOWER MOTOR RESISTORS (BEHIND RIGHT SIDE OF I/P)
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
DASH FUSE BOX
HEATER CONTROL UNIT
HOT AT ALL TIMES
HOT IN RUN
OFF
ORG/BLU WIRE
POWERTRAIN CONTROL MODULE (BEHIND LEFT SIDE OF I/P)
R WIPER FUSE
RED WIRE
RED/BLK WIRE
WHT/GRN WIRE
