Ford Aspire I (1993-1997) left front door switch Wiring diagram
This page shows the only wiring diagram for the component.left front door switch, which is found in the car Ford Aspire I (1993-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front door switch (1 of 1)
BLK WIRE
BLU WIRE
DASH FUSE BOX (LEFT SIDE OF I/P)
DOME LAMP
HEAD OFF PARK
HEADLAMP SWITCH
HEATER- A/C CONTROL UNIT
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMING RHEOSTAT
JOINT CONNECTOR
LEFT FRONT DOOR SWITCH
LIFTGATE SWITCH
LT BLU/RED WIRE
LUGGAGE COMPARTMENT SWITCH ASSEMBLY
MULTI- FUNCTION SWITCH
OFF ON
OFF ON DOOR
PARKING LAMPS RELAY (RIGHT FRONT OF ENGINE)
RADIO
REAR WINDOW DEFROSTER/ FOG LAMP SWITCH RADIO
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT FRONT DOOR SWITCH
ROOM FUSE
STOP FUSE
TAIL FUSE
TRANSMISSION RANGE ILLUMINATION (W/ A/T ONLY)
W/ PREMIUM SOUND
W/O PREMIUM SOUND
WARNING CHIME MODULE (BEHIND LEFT SIDE OF I/P)
WHT WIRE
YEL WIRE
Go to component -> Interior light circuit -> LEFT FRONT DOOR SWITCH
