Supplemental restraint circuit for Ford Aerostar I (1986-1997)
Supplemental restraint circuit
AIR BAG SAFING SENSOR (BEHIND LEFT COWL PANEL)
BLK WIRE
BLK/YEL WIRE
CENTER RADIATOR CRASH SENSOR (ON UPPER RADIATOR SUPPORT)
CLOCK SPRING ASSEMBLY
DK BLU/WHT WIRE
DRIVER'S AIR BAG
FEED MONITOR
FUSE 5 FUSE 10
GROUND
GROUND 8 9
GROUND INDICATOR 4 5
GRY/ORG WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT IN RUN FUSE PANEL
IGNITION BATTERY
IGNITION GROUND 2 3
INSTRUMENT CLUSTER AIR BAG INDICATOR
NCA WIRE
PNK/ORG WIRE
PNK/WHT WIRE
PPL/LT BLU WIRE
PPL/LT GRN WIRE
PPL/ORG WIRE
PPL/WHT WIRE
RIGHT KICK PANEL CRASH SENSOR
WHT/ORG WIRE
YEL WIRE
