Am radio circuit for Ford Aerostar I (1986-1997)
Am radio circuit
8 7 6 5 4 3 2 1 BATTERY
BLK/LT GRN WIRE
BLK/WHT WIRE
BRN/ORG WIRE
DK BLU/ORG WIRE
FUSE 11
FUSE 8
FUSE PANEL (BEHIND LEFT END OF DASH)
HOT AT ALL TIMES
HOT IN ACC OR RUN
LEFT FRONT SPEAKER
LT BLU/RED WIRE
LT GRN/YEL WIRE
NOT USED
ORG/BLK WIRE
ORG/LT GRN WIRE
PNK/LT BLU WIRE
PNK/LT GRN WIRE
PNK/YEL WIRE
RADIO
RADIO PWR ILLUMINATION LCD DISPLAY GROUND
RED/BLK WIRE
RIGHT FRONT SPEAKER
TAN WIRE
WHT/LT GRN WIRE
WHT/PPL WIRE
YEL/BLK WIRE
