Power door lock circuit for Ford Aerostar I (1986-1997)
Power door lock circuit
7 8 LK SLDG DR CNTL BAT
BLK WIRE
BLK/WHT WIRE
BUTTON CONNECTORS
DOOR LOCK/UNLOCK CONTROL RELAY
FUSE LINK
GROUND
HOT AT ALL TIMES
IN-LINE FUSE
LEFT FRONT DOOR LOCK MOTOR
LIFTGATE DOOR LOCK MOTOR
LOCK
MASTER WINDOW/DOOR LOCK SWITCH
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
PNK/LT GRN WIRE
PNK/ORG WIRE
PNK/YEL WIRE
POWER DOOR LOCK MODULE (LEFT FRONT OF CARGO AREA, BEHIND LEFT "B" PILLAR)
RIGHT FRONT DOOR LOCK MOTOR
RIGHT REAR DOOR LOCK MOTOR
RIGHT WINDOW/DOOR LOCK SWITCH
SLIDING DOOR LOCK MOTOR
UN LOCK
UNLK CNTL LOCK CNTL
UNLOCK
WITH DUAL REAR DOORS
WITH LIFTGATE
YEL/BLK WIRE
