Instrument illumination circuit for Ford Aerostar I (1986-1997)
Instrument illumination circuit
A/C- HEATER CONTROL ILLUMINATION
ASHTRAY LAMP
BLK WIRE
BLK/LT GRN WIRE
BRN WIRE
FUSE 11
FUSE 13
FUSE 4
FUSE PANEL
HOT AT ALL TIMES
HOT IN ACCY OR RUN
IGN
ILLUMINATION
INSTRUMENT CLUSTER
INSTRUMENT PANEL CIGAR LIGHTER LAMP
LCD DISPLAY
LIFTGATE WIPER/ WASHER SWITCH
LT BLU/RED WIRE
MAIN LIGHT SWITCH
OFF HEAD
OFF HEAD DIMMER
ORG/BLK WIRE
PARK
POWER DISTRIBUTION SYSTEM
RADIO
REAR AUXILIARY BLOWER MOTOR SWITCH ILLUMINATION
REAR CIGAR LIGHTER
REAR CIGAR LIGHTER ILLUMINATION
REAR WINDOW DEFROST CONTROL
REMOTE HEADPHONE MODULE
TAN/WHT WIRE
W/ AUXILIARY BLOWER MOTOR
YEL/BLK WIRE
