FIAT 500X I (2014-2018) Cooling fan circuit

1.4L TURBO 2.4L 2.4L 1.4L TURBO A/C PRESS SIG A/C PRESSURE TRANSDUCER AUXILIARY POWER DISTRIBUTION CENTER ASSEMBLY BLK WIRE BLK/VIO WIRE BRN WIRE BRN/VIO WIRE DK BLU/RED WIRE ECT SIG ELECTRIC COOLANT ELECTRIC COOLANT PUMP CTRL ENGINE CONTROLS SYSTEM ENGINE COOLANT ENGINE COOLANT PUMP SIG ENGINE COOLANT TEMPERATURE SENSOR FUSE 14 FUSE 6 FUSE 7 HOT AT ALL TIMES LOW RAD FAN RLY CTRL LT GRN WIRE ORG/BLK WIRE POWER DISTRIBUTION CENTER ASSEMBLY POWERTRAIN CONTROL MODULE PUMP O/P PUMP SIG RAD FAN CTRL RADIATOR FAN 1 RESISTOR RADIATOR FAN COOLING 1 MODULE RADIATOR FAN ENABLE SIG RADIATOR FAN HIGH 2 RELAY RADIATOR SERIES/ PARALLEL FAN RELAY RED/BLK WIRE RED/BLU WIRE RED/LT GRN WIRE RED/YEL WIRE S238 (2.4L) SENS GND SENSOR GND SK901 (1.4L TURBO) S1070 (2.4L) TURBO COOLANT PUMP MOTOR VIO/YEL WIRE WATER AFTER RUN PUMP RELAY WHT WIRE WHT/LT GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/LT GRN WIRE
