Backup lamps circuit, electric for FIAT 500 II facelift (2015-2024)
Backup lamps circuit, electric
BLK WIRE
BODY CONTROL MODULE
BRN/VIO WIRE
CAN B
CAN C (+)
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
E PRND MODULE (LEFT SIDE OF DASH)
ELECTRIC VEHICLE CONTROL UNIT
FSD B(+)
FUSE 1
FUSE 11
FUSED B (+)
GRY WIRE
GRY/DK GRN WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ MAIN RELAY ENERGIZED
LEFT TAIL LAMP ASSEMBLY
LH BKUP
LH BKUP LP DRV
LP DRV
PARK IND
POWER DISTRIBUTION CENTER ASSEMBLY
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
REVERSE
REVERSE IND
RH BKUP
RH BKUP LPS FD
RIGHT TAIL LAMP ASSEMBLY
TRANS REV SIG
TRANS REV SW SIG
WHT WIRE
WHT/DK BLU WIRE
WHT/LT GRN WIRE
