Car Wiring Diagrams for Cruise control circuit for FIAT 124 Spider I (2016-2020)

ACCELERATOR PEDAL POSITION SENSOR BLK WIRE BLK/DK BLU WIRE BLK/RED WIRE BLU WIRE BRAKE PEDAL SWITCH (BRAKE PEDAL ASSEMBLY) BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 29 FUSE 35 FUSE 4 GRN WIRE GRY/DK BLU WIRE HOT AT ALL TIMES JUNCTION UNIT ORG/BLK WIRE POWERTRAIN CONTROL MODULE RED WIRE RED/VIO WIRE RELAY ENERGIZED THROTTLE BODY (INTAKE MANIFOLD INLET) VIO WIRE WHT WIRE WHT/BLK WIRE WHT/VIO WIRE YEL/DK BLU WIRE

AA PNK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE CLUSTER COMPUTER DATA LINES SYSTEM CRUISE CONTROL SWITCH CRUISE IND (AMBER) CRUISE IND (GREEN) DK BLU WIRE GRN WIRE GRN/DK BLU WIRE INFO INPUT SPEED SENSOR NCA WIRE OFF/ CANC ON/ MODE ORG/ WIRE OUTPUT SPEED SENSOR PARK ASSIST MODULE PNK WIRE RADIO (BASE) RADIO (PREMIUM 1) RADIO FREQUENCY HUB MODULE RED WIRE RES+ RIGHT RADIO REMOTE SWITCH SET- STEERING COLUMN CONTROL MODULE TAN WIRE TRANSMISSION ASSEMBLY TRANSMISSION CONTROL MODULE VIO WIRE WHT WIRE YEL WIRE
