FIAT 124 Spider I (2016-2020) handsfree microphone shield Wiring diagram
This page shows the only wiring diagram for the component.handsfree microphone shield, which is found in the car FIAT 124 Spider I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram handsfree microphone shield (1 of 1)
A/T
BASE
BLK WIRE
BLUETOOTH CONTROL MODULE
BLUETOOTH CONTROL MODULE SHIELD
CENTER BANK SWITCH
CIGAR LIGHTER
CLUSTER
CLUSTER GAUGE PACK
DATA LINK CONNECTOR
DECKLID RELEASE SWITCH 1
DRIVER MIRROR WINDOW SWITCH
DRIVER OUTSIDE REAR- VIEW MIRROR
DRIVING MODE SELECTION SWITCH
ELECTRO- CHROMATIC MIRROR
FRONT DOME LAMP
HANDSFREE MICROPHONE SHIELD
HAZARD LIGHTS SWITCH
HEADLAMP LEVELING MODULE
HVAC CONTROL MODULE
INTEGRATED CENTER STACK MODULE
KEYLESS IGNITION NODE MODULE
LEFT BANK SWITCH
MICROPHONE NOISE CANCELLATION SHIELD
NCA WIRE
PREMIUM
PREMIUM, PREMIUM 2 BASE
PRNDL LAMP
RADIO
RADIO SHIELD
RADIO, AMPLIFIER
RADIO, AMPLIFIER SHIELD
RAIN LIGHT SENSOR MODULE
SCREEN CENTER STACK DISPLAY
SCREEN CENTER STACK DISPLAY SHIELD
SHIELD
SHIFT LEVER ASSEMBLY
STEERING COLUMN CONTROL MODULE
TOP LATCHED SENSOR
USB PORT
USB PORT 2 SHIELD
USB PORT SHIELD
Go to component -> Ground distribution circuit (1 of 3) -> HANDSFREE MICROPHONE SHIELD
