FIAT 124 Spider I (2016-2020) cylinder switch Wiring diagrams

This page contains all the electrical diagrams for the component. cylinder switch, in which he is found in the car FIAT 124 Spider I (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

cylinder switch wiring diagram (1 of 4)

BLK WIRE BLK/DK BLU WIRE BLU WIRE BODY CONTROL MODULE (LEFT END OF DASH) BRN WIRE BUZZER CLUSTER COMPUTER DATA LINES SYSTEM CYLINDER SWITCH DK BLU WIRE DK BLU/BLK WIRE DOOR OPEN DRIVER DOOR LATCH DRIVER MIRROR WINDOW SWITCH FILLER CAP FUEL DOOR MOTOR FUSE 10 FUSE 7 GRN WIRE GRN/ORG WIRE GRN/VIO WIRE GRY WIRE HOT AT ALL TIMES IND JUNCTION UNIT LOCK LOCK LINK SWITCH LOOSE FUEL RADIO FREQUENCY HUB MODULE RED WIRE RELAY ENERGIZED TAN WIRE UNLOCK VIO WIRE WARNING WHT WIRE WHT/BLK WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE

Go to component -> Forced entry circuit, base (1 of 2) -> CYLINDER SWITCH

cylinder switch wiring diagram (2 of 4)

BLK WIRE BLK/DK BLU WIRE BLU WIRE BRN WIRE BUZZER CLUSTER COMPUTER DATA LINES SYSTEM CYLINDER SWITCH DK BLU WIRE DOOR OPEN DRIVER DOOR LATCH DRIVER MIRROR WINDOW SWITCH FILLER CAP FUEL DOOR MOTOR GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRY WIRE GRY/GRN WIRE IND LOCK LOCK LINK SWITCH LOOSE FUEL PASSIVE ENTRY ANTENNA 4 PASSIVE ENTRY ANTENNA 6 RED WIRE RIGHT FRONT DOOR HANDLE EXTERIOR SWITCH TAN WIRE UNLOCK VIO WIRE WARNING WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Forced entry circuit, premium (2 of 3) -> CYLINDER SWITCH
