FIAT 124 Spider I (2016-2020) anti interference filter Wiring diagram
This page shows the only wiring diagram for the component.anti interference filter, which is found in the car FIAT 124 Spider I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram anti interference filter (1 of 1)
ANTI INTERFERENCE FILTER
AUXILIARY POWER DISTRIBUTION CENTER ASSEMBLY
BLK WIRE
BODY CONTROL MODULE
CIRCUIT BOARD
CLUSTER
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DRIVER OUTSIDE REAR- VIEW MIRROR
ELECTRIC HEATED BACKLITE
FUSE 10
FUSE 16
FUSE 47
GRN WIRE
HOT AT ALL TIMES
HVAC CONTROL MODULE
JUNCTION UNIT
PASSENGER OUTSIDE REAR VIEW MIRROR
PNK WIRE
REAR WINDOW DEFOGGER RELAY
RED WIRE
RELAY ENERGIZED
VIO WIRE
WHT WIRE
Go to component -> Defoggers circuit -> ANTI INTERFERENCE FILTER
