Eagle Vision I (1992-1997) Wiper/washer circuit

BLK WIRE BLK/TAN WIRE BODY CONTROL MODULE RELAY CONTROL BRN WIRE DELAY DK BLU WIRE DK GRN/YEL WIRE HI OFF HIGH-LOW WIPER RELAY HOT AT ALL TIMES HOT IN ACCY OR RUN INT LO INTER- MITTENT WIPER RELAY INTERMITTENT SENSE JUNCTION BLOCK LT GRN/BLK WIRE ON OFF POWER DISTRIBUTION CENTER RED WIRE RED/DK BLU WIRE TAN/RED WIRE VIO WIRE WASHER SWITCH WHT WIRE WINDSHIELD WASHER LOW FLUID LEVEL SENSOR WINDSHIELD WASHER LOW WASHER FLUID WINDSHIELD WASHER PUMP MOTOR WIPER MOTOR WIPER PARK SWITCH HI/LO RELAY CONTROL WIPER/WASHER SWITCH WIPER SWITCH YEL WIRE
