Eagle Vision I (1992-1997) cruise ctrl mode sel Wiring diagram
This page shows the only wiring diagram for the component.cruise ctrl mode sel, which is found in the car Eagle Vision I (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cruise ctrl mode sel (1 of 1)
BLK WIRE
BLK/LT GRN WIRE
BRAKE SW
CLOCKSPRING ASSEMBLY
CRUISE CONTROL
CRUISE CTRL MODE SEL
CRUISE CTRL SW
CRUISE CTRL VACUUM
CRUISE CTRL VENT
DK BLU/RED WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
JUNCTION BLOCK
LT GRN/RED WIRE
NCA WIRE
OFF
PNK/DK BLU WIRE
POWERTRAIN CONTROL MODULE (RIGHT FENDER SIDE SHIELD)
RED/LT GRN WIRE
RELAY
RESUME
STOP LAMP SWITCH (ON STEERING COLUMN SUPPORT)
STOP LTS
TAN/RED WIRE
VEHICLE SPEED CONTROL SERVO (LEFT REAR OF ENGINE COMPARTMENT)
VEHICLE SPEED CONTROL SW
WHT/PNK WIRE
WHT/TAN WIRE
YEL/RED WIRE
Go to component -> Cruise control circuit -> CRUISE CTRL MODE SEL
