Eagle Vision I (1992-1997) body control module relay control Wiring diagram
This page shows the only wiring diagram for the component.body control module relay control, which is found in the car Eagle Vision I (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram body control module relay control (1 of 1)
BLK WIRE
BLK/TAN WIRE
BODY CONTROL MODULE RELAY CONTROL
BRN WIRE
DELAY
DK BLU WIRE
DK GRN/YEL WIRE
HI OFF
HIGH-LOW WIPER RELAY
HOT AT ALL TIMES
HOT IN ACCY OR RUN
INT LO
INTER- MITTENT WIPER RELAY
INTERMITTENT SENSE
JUNCTION BLOCK
LT GRN/BLK WIRE
ON OFF
POWER DISTRIBUTION CENTER
RED WIRE
RED/DK BLU WIRE
TAN/RED WIRE
VIO WIRE
WASHER SWITCH
WHT WIRE
WINDSHIELD WASHER LOW FLUID LEVEL SENSOR
WINDSHIELD WASHER LOW WASHER FLUID
WINDSHIELD WASHER PUMP MOTOR
WIPER MOTOR
WIPER PARK SWITCH HI/LO RELAY CONTROL
WIPER/WASHER SWITCH WIPER SWITCH
YEL WIRE
Go to component -> Wiper/washer circuit -> BODY CONTROL MODULE RELAY CONTROL
