Eagle Vision I (1992-1997) 4 10 13 20 mode door ambient sens evap sens sun sensor Wiring diagram

1 2 3 4 5 6 7 8 DIMMER SW INPUT GROUND CCD BUS (+) CCD BUS (-) 1 2 DEFOGGER RELAY BATTERY 4 10 13 20 MODE DOOR AMBIENT SENS EVAP SENS SUN SENSOR 7 8 15 CCD (-) CCD (+) SENS GROUND A/C AMBIENT TEMPERATURE SENSOR (LEFT FRONT BUMPER) A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY A/C PRESSURE TRANSDUCER (RIGHT SIDE OF RADIATOR) ATC POWER MODULE (RIGHT SIDE OF HVAC HOUSING) AUTOMATIC TEMPERATURE CONTROL MODULE (CENTER OF I/P) BLEND DOOR ACTUATOR (LOWER CENTER OF HVAC HOUSING) BLK WIRE BLK/LT BLU WIRE BLK/LT GRN WIRE BLK/PNK WIRE BLK/WHT WIRE BLOWER MOTOR BODY CONTROL MODULE (RIGHT KICK PANEL) DK BLU WIRE DK BLU/BLK WIRE DK BLU/ORG WIRE DK BLU/PNK WIRE DK BLU/RED WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/YEL WIRE EVAPORATOR TEMPERATURE SENSOR (IN EVAPORATOR) FUSE 21 FUSE 20 FUSE 6 FUSIBLE LINK GROUND IGNITION GRY WIRE GRY/DK BLU WIRE GRY/TAN WIRE HIGH SPEED RADIATOR FAN RELAY (IN POWER DISTRIBUTON CENTER) HOT AT ALL TIMES HOT IN RUN HOT IN RUN OR START IN-CAR TEMPERATURE SENSOR/ ASPIRATOR MOTOR (ABOVE GLOVE BOX) INTERIOR LIGHTS (HEADLIGHT SWITCH) JUNCTION BLOCK FUSE 13 LOW SPEED FAN MOTOR HIGH SPEED FAN MOTOR LOW SPEED RADIATOR FAN RELAY (IN POWER DISTRIBUTON CENTER) LT GRN/BLK WIRE MODE DOOR ACTUATOR (LOWER LEFT SIDE OF HVAC HOUSING) NCA WIRE ORG/ WIRE PNK WIRE PNK/DK BLU WIRE POWER DISTRIBUTION CENTER FUSE POWERTRAIN CONTROL MODULE (RIGHT FENDER SIDE SHIELD) RADIATOR FAN MOTOR ASSEMBLY REAR DEFOGGER (DEFOGGER GRID) RECIRCULATION DOOR ACTUATOR (RIGHT SIDE OF HVAC HOUSING) RED WIRE RED/LT GRN WIRE RED/TAN WIRE RED/WHT WIRE SUN SENSOR (TOP CENTER OF I/P) TAN WIRE VIO/BRN WIRE VIO/LT GRN WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE YEL DK GRN/ WIRE YEL WIRE YEL/DK GRN WIRE
