Eagle Summit I (1989-1996) Supplemental restraint circuit

AIR BAG MODULE BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE CLOCK- SPRING CONNECTOR LOCK SWITCH (IN SRS DIAGNOSIS UNIT CONNECTOR) DATA LINK CONNECTOR (BELOW LEFT I/P) ENGINE COMPARTMENT RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT) GRN/RED WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT CLUSTER IOD OR STORAGE CONNECTOR JUNCTION BLOCK (BELOW LEFT I/P) MULTI- PURPOSE FUSE 11 MULTI- PURPOSE FUSE 18 MULTI-PURPOSE FUSE 19 NCA WIRE RED WIRE RED/BLK WIRE SRS SRS DIAGNOSIS UNIT (BETWEEN FRONT SEATS) YEL/BLK WIRE
