Instrument illumination circuit for Eagle Summit I (1989-1996)

ASHTRAY ILLUMINATION LIGHT BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE CIGARETTE LIGHTER ILLUMINATION LIGHT CLOCK COLUMN SWITCH DEDICATED FUSE 3 ENGINE COMPARTMENT RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT) GRN WIRE GRN/WHT WIRE HEAD OFF TAIL HEATER CONTROL ILLUMINATION LIGHT HOT AT ALL TIMES ILLUMINATION INSTRUMENT CLUSTER JUNCTION BLOCK (BELOW LEFT I/P) LEFT CLUSTER SWITCH ILLUMINATION LIGHT NCA WIRE OD OFF OVERDRIVE SWITCH RADIO (OR) RADIO WITH TAPE PLAYER RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RHEOSTAT RIGHT CLUSTER SWITCH ILLUMINATION LIGHT SUB FUSIBLE LINK 4 TAILLIGHT RELAY TRANSMISSIONS SYSTEM YEL WIRE YEL/BLK WIRE YEL/RED WIRE
