Eagle Summit I (1989-1996) keyless entry control unit (left quarter panel forward of wheel well) wiring diagram
This page shows the only wiring diagram for the component.keyless entry control unit (left quarter panel forward of wheel well), which is found in the car Eagle Summit I (1989-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
keyless entry control unit (left quarter panel forward of wheel well) wiring diagram (1 of 1)
AUTOMATIC SEAT BELT CONTROL UNIT (BETWEEN FRONT SEATS)
BLK RED/ WIRE
BLK WIRE
BUZZER ASSEMBLY (BEHIND CENTER OF I/P)
CARGO LIGHT
DIODE
DOME LIGHT * W/ SUNROOF
DOOR
ENGINE COMPARTMENT RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT)
GRN RED/ WIRE
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
IOD OR STORAGE CONNECTOR
JUNCTION BLOCK (BELOW LEFT I/P)
KEYLESS ENTRY CONTROL UNIT (LEFT QUARTER PANEL FORWARD OF WHEEL WELL)
LEFT FRONT DOOR SWITCH RIGHT FRONT DOOR SWITCH
LIFTGATE SWITCH
MULTI-PURPOSE FUSE 19
OFF
OFF 1 2 DOOR
ON OFF
REAR DOOR SWITCH
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
W/ KEYLESS ENTRY W/O KEYLESS ENTRY
W/O KEYLESS ENTRY W/ KEYLESS ENTRY
YEL RED/ WIRE
YEL WIRE
Go to component -> Courtesy lamp circuit -> KEYLESS ENTRY CONTROL UNIT (LEFT QUARTER PANEL FORWARD OF WHEEL WELL)
