Eagle Summit I (1989-1996) automatic seat belt control unit (u.s. models) (between front seats) wiring diagram
This page shows the only wiring diagram for the component.automatic seat belt control unit (u.s. models) (between front seats), which is found in the car Eagle Summit I (1989-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
automatic seat belt control unit (u.s. models) (between front seats) wiring diagram (1 of 1)
AUTOMATIC SEAT BELT CONTROL UNIT (U.S. MODELS) (BETWEEN FRONT SEATS)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BUZZER ASSEMBLY (BEHIND CENTER
CANADA MODELS
CLUTCH PEDAL POSITION SWITCH
DEDICATED FUSE 2
ENGINE COMPARTMENT RELAY BOX
ENGINE COMPARTMENT RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT)
GRN WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER
IOD OR STORAGE CONNECTOR
JUNCTION BLOCK (BELOW LEFT I/P)
KEY REMINDER SWITCH (ON IGNITION SWITCH) U.S MODELS
LEFT FRONT DOOR SWITCH (BASE OF LEFT "B" PILLAR)
MULTI- PURPOSE FUSE 14
MULTI- PURPOSE FUSE 3
NCA WIRE
OF I/P)
OFF
OFF ON SEAT BELT BUCKLE SWITCH
ON OFF
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
SEAT BELT INDICATOR
TAILLIGHT RELAY PIN 4
US MODELS
WHT GRN/ WIRE
WHT RED/ WIRE
WHT WIRE
WHT/ BLK WIRE
WHT/GRN WIRE
YEL WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Warning system circuits -> AUTOMATIC SEAT BELT CONTROL UNIT (U.S. MODELS) (BETWEEN FRONT SEATS)
