Dodge Stratus I (1995-2000) solenoid driver Wiring diagram
This page shows the only wiring diagram for the component.solenoid driver, which is found in the car Dodge Stratus I (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram solenoid driver (1 of 1)
A/T
BLK WIRE
BLK/TAN WIRE
FUSE 4
HOT IN RUN
IGNITION GROUND VSS SIGNAL
JUNCTION BLOCK (UNDER LEFT SIDE OF DASH)
LEFT FRONT STRUT TOWER)
LT GRN WIRE
M/T
NCA WIRE
RED WIRE
SOLENOID CONTROL VALVE
SOLENOID DRIVER
SPEED PROPORTIONAL STEERING MODULE (ON LEFT SIDE OF STEERING GEAR)
TAN WIRE
VEHICLE SPEED SENSOR (LEFT REAR OF TRANSMISSION)
VSS SIGNAL
WHT WIRE
WHT/LT GRN WIRE
WHT/ORG WIRE
Go to component -> Electronic power steering circuit -> SOLENOID DRIVER
