Dodge Stratus I (1995-2000) left tail/stop, turn signal lamp assembly wiring diagram
This page shows the only wiring diagram for the component.left tail/stop, turn signal lamp assembly, which is found in the car Dodge Stratus I (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left tail/stop, turn signal lamp assembly wiring diagram (1 of 1)
ANTI- LOCK BRAKE CONTROLLER
BLK WIRE
BLK/BRN WIRE
BLK/YEL WIRE
BODY CONTROL MODULE
BREEZE, STRATUS
BRN WIRE
CENTER HIGH MOUNTED STOP LAMP
CIRRUS
CIRRUS RIGHT TURN LAMP (BREEZE, STRATUS) RIGHT TAIL/ TURN LAMP (CIRRUS)
COMBINATION FLASHER
DK BLU WIRE
FUSE 14
FUSE 15
FUSE 4
FUSE 6
FUSE 7
FUSE 8
GROUND
HEAD OFF PARK
HEADLAMP SWITCH
HOT AT ALL TIMES
IGNITION SWITCH
INSTRUMENT CLUSTER
JUNCTION BLOCK
LEFT "C" PILLAR)
LEFT FRONT STRUT TOWER)
LEFT PARK/ TURN SIGNAL LAMP
LEFT SIDE MULTI-FUNCTION SWITCH
LEFT TAIL LAMP
LEFT TAIL/ STOP LAMP
LEFT TAIL/STOP, TURN SIGNAL LAMP ASSEMBLY
LEFT TURN LAMP (BREEZE, STRATUS) LEFT TAIL/ TURN LAMP (CIRRUS)
LEFT TURN SIGNAL INDICATOR
LICENSE PLATE LAMP
LOCK OFF
LT GRN WIRE
LT GRN/TAN WIRE
ORG/ WIRE
PK LP SW OUT
PNK WIRE
POWER DISTRIBUTION CENTER
RED WIRE
RIGHT PARK/ TURN SIGNAL LAMP
RIGHT TAIL/ STOP LAMP RIGHT TAIL LAMP
RIGHT TAIL/STOP, TURN SIGNAL LAMP ASSEMBLY
RIGHT TURN SIGNAL INDICATOR
RUN WIRE
TAN WIRE
TAN/BRN WIRE
TURN SIGNAL/ HAZARD WARNING SWITCH
WHT WIRE
WHT/TAN WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> LEFT TAIL/STOP, TURN SIGNAL LAMP ASSEMBLY
