Dodge Stratus I (1995-2000) left front door ajar switch left rear door ajar switch Wiring diagram
This page shows the only wiring diagram for the component.left front door ajar switch left rear door ajar switch, which is found in the car Dodge Stratus I (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front door ajar switch left rear door ajar switch (1 of 1)
A/C HEATER CONTROL
ASH RECEIVER LAMP
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/TAN WIRE
BLK/YEL WIRE
BODY CONTROL MODULE
DIMMER SIGNAL CTSY LAMPS DRIVER
DOME LAMP
DOOR
GLOVE BOX LAMP)
GROUND
GROUND DISTRIBUTION
HEAD OFF PARK
HEADLAMP SWITCH
HOT AT ALL TIMES FUSE 5
HOT AT ALL TIMES FUSE 7
INSTRUMENT CLUSTER
JUNCTION BLOCK (UNDER LEFT SIDE OF DASH)
KEY-IN HALO LAMP (RIGHT SIDE OF COLUMN)
LEFT FRONT DOOR AJAR SWITCH LEFT REAR DOOR AJAR SWITCH
LEFT VISOR/VANITY LAMP
OFF
ORG/ WIRE
ORG/BRN WIRE
ORG/GRY WIRE
ORG/YEL WIRE
OVERHEAD MAP LAMP
PNK WIRE
PNK/ORG WIRE
PNK/WHT WIRE
PRNDL ILLUMINATION LED
RADIO
RED WIRE
RIGHT FRONT DOOR AJAR SWITCH
RIGHT REAR DOOR AJAR SWITCH
RIGHT VISOR/VANITY LAMP
TAN WIRE
TAN/BLK WIRE
TAN/ORG WIRE
TAN/PNK WIRE
TAN/RED WIRE
TRUNK AJAR SWITCH (ON LATCH)
TRUNK LAMP
YEL WIRE
YEL/RED WIRE
Go to component -> Interior light circuit -> LEFT FRONT DOOR AJAR SWITCH LEFT REAR DOOR AJAR SWITCH
